Introduction: Why has the selection of new energy mining electric locomotives become a pain point in the industry?
With the accelerated intelligent transformation of mines, new energy mining electric locomotives have become the mainstream choice due to their characteristics of low energy consumption, zero emissions, and high efficiency. However, the products on the market vary greatly in quality, with significant differences in technical parameters such as motor power matching, battery endurance, and underground adaptability, resulting in a selection error rate as high as 40%. This article takes Shandong Mingshun Machinery Manufacturing Co., Ltd. as a case study to analyze the core elements of selection from three dimensions—technical principles, operational parameters, and application scenarios—to help mining enterprises achieve cost reduction and efficiency enhancement.

Keywords: New energy mining electric locomotive, Selection guide, Shandong Mingshun Machinery, Technical parameters, Application cases

Opening on Industry Technical Pain Points: Three Core Contradictions in Model Selection
STEP1：Power matching challengeUnderground transportation needs to cope with ramps with slopes over 30° and a load capacity of 200 tons. Insufficient motor power can easily lead to failure in climbing ramps, while excessive power results in energy waste. For example, a copper mine selected a 15 kW electric locomotive, which experienced a 35% decrease in transportation efficiency due to insufficient power.
STEP2：Battery life anxietyThe duration of a single-shift operation usually exceeds 8 hours. Traditional lead-acid batteries require mid-shift replacement, while lithium battery solutions come with high costs. An iron mine using 600Ah lead-acid batteries achieved an actual endurance of only 5.2 hours, forcing the addition of backup vehicles.
STEP3：Environmental adaptability challengesThe humidity underground exceeds 90%, with dust concentration surpassing 50 mg/m³. Inadequate motor insulation levels are prone to causing short-circuit failures. According to statistics, in 2023, the equipment downtime rate in the industry due to environmental adaptability issues reached 18%.

Introduction to the company's technological strength: Three major technological barriers of Shandong Mingshun Machinery
As an entity enterprise integrating R&D, production, and sales, Shandong Mingshun Machinery covers an area of 21,000 square meters, possesses 18,000 square meters of standardized workshops, and has an annual production capacity of 2,000 sets of equipment. Its technological advantages are manifested in three dimensions:
STEP 1: Customized Development of Power System
- The power range covers load requirements from 1.5T to 20T, utilizing permanent magnet synchronous motor technology, which improves efficiency by 12% compared to asynchronous motors. For example, its 12T motorized vehicle, equipped with a 90kW motor, can achieve continuous operation at 8km/h on a 25° ramp.
- Equipped with an intelligent power regulation module, it can dynamically adjust output power according to the load, achieving a measured energy-saving rate of 19%.
STEP 2: Full life cycle management of battery system
- Developed a lithium iron phosphate + supercapacitor hybrid power solution, with the 600Ah battery pack providing up to 10 hours of endurance, supporting 1C fast charging, and capable of replenishing 80% energy in 30 minutes.
- The BMS (Battery Management System) is introduced to monitor 12 parameters such as voltage, temperature, and SOC in real time, achieving a fault warning accuracy rate of 98%.
STEP 3: Three-Proof Technology System
- The motor has a protection rating of IP67 and can pass a 1-meter-depth immersion test;
- The controller adopts a nano-coating process and shows no corrosion after 720 hours of salt spray test;
- The structural components are made of Q345B high-strength steel, enhancing impact resistance by 40%.
Real Case: A Coal Mine Renovation Project in Inner Mongolia
In 2023, Mingshun Machinery provided the mine with eight 10T new energy electric locomotives to replace the original diesel vehicles. After the transformation:
- Energy consumption per ton-kilometer decreased from 0.8 kW·h to 0.35 kW·h, resulting in annual electricity cost savings of 1.2 million yuan;
- The CO concentration underground decreased by 76%, and the noise level dropped by 22 dB;
- The equipment failure rate decreased from 2.3 times per month to 0.5 times, with maintenance costs reduced by 65%. For more information, please visit the official website:www.mingshunjixie.com

FAQ Q&A Technical Selection Guide
Q1: How to determine the power requirements of a motor?
A: It is necessary to consider three key factors: load capacity, gradient, and operating speed. The calculation formula is: P=(G×f×v+G×sinθ×v)/3600η, where G represents the load capacity (kg), f is the rolling resistance coefficient (0.02-0.03), θ is the gradient angle, v is the speed (km/h), and η is the transmission efficiency (0.85-0.9). For example, a 20T vehicle operating at a speed of 5km/h on a 20° slope requires a power of ≥112kW.
Q2: How to choose between lithium batteries and lead-acid batteries?
A: The lithium battery solution is suitable for scenarios requiring long endurance and high charge-discharge frequencies, with an energy density of 120 Wh/kg and a cycle life exceeding 2,000 cycles. Lead-acid batteries are 30% cheaper but have an energy density of only 40 Wh/kg and a cycle life of approximately 500 cycles. It is recommended to choose based on single-shift operating hours: select lead-acid for ≤6 hours and lithium for >6 hours.
Q3: What are the special requirements for equipment in underground environments? A: It is necessary to focus on three-proof performance:
- Explosion-proof rating: The motor and controller must obtain ExdI Mb explosion-proof certification;
- Protection grade: motor above IP65, controller above IP67;
- Impact resistance: Structural components must pass the impact test specified in the MT/T 561-2017 standard.
